Cast Iron Check Valve

PN:

16~250

DN:

15~1400

Material:

WCB, A105, LCC, LF2, 20ГЛ, 20ГМЛ, SS304, SS321, SS316, SS316Ti

DRIVE:

Manual, Electric, Pneumatic

Connection:

Flange, Welded, Threaded

Medium:

Water, steam, oil, chemical

The valve disc of the swing check valve is disc shaped and rotating around the seat channel. Because the valve channel is streamlined, the flow resistance is smaller than the lift check valve. It is suitable for a large aperture with low flow velocity and unchangeable flow, but it is not suitable for pulsating flow, and its sealing performance is less than the lifting type. The swing check valve is divided into three types, single valve, double valve and multi half. These three forms are divided mainly according to the valve diameter. The purpose is to prevent the hydraulic shock from stopping the flow or reverse flow of the medium.

ype	Ball/Swing/Rubber Flap
Face to Face	DIN3202 F6
Flange	PN6/PN10/PN16/PN25, 125LB/150LB, JIS5K/10K/16K, TABLE D/E
Flange Face	Flat Face/Raised Face
Working Pressure	PN16
Application	Water works, Public facilities, Building Industry, Petroleum, Chemical, Steel, Metallurgy, Paper Making Industry, Foods, Beverage
